Know About Screw L/D Ratio
15th, August, 2016
The L/D ratio is the ratio of the length of the screw to its outside diameter. The ratio calculation is calculated by dividing the length of the screw by its nominal diameter. Although several injection molding machine manufacturers now offer a choice of injection units, most injection screws use a 20:1 L/D ratio.
Screw ratio (L/D) meaning how long it is compared to its diameter. As an example, the L/D ratio for PP and PE is in the range 20-30:1.
The effect of changing the L/D ratio can be summarized in the following manner: the larger the ratio (longer length), the:
More shear heat can be uniformly generated in the plastic without degradation;
Greater the opportunity for mixing, resulting in a better homogeneity of the melt;
Greater the residence time of the plastic in the barrel possibly permitting faster cycles of larger shots.
